CHAUD!! Crépines anti-incendie de type Y DN20
-
marque
LEFILTER -
modèle:
-
brève introduction
CHAUD!! Crépines anti-incendie de type Y DN20
Télé:+ 86-373-2618077
E-mail:export@lefilter.com
Présentation
INTRODUCTION:
Y type strainer is usually used at the inlet end of reducing valve, decompression valve, level control valve and other equipment to clear the impurities in the medium so that the vlave and equipment can work normally. When the liquid flows through the filter wire mesh, the solid particles are stopped by the filter wire mesh so that the clean liquid can flow through the mesh and flow out from the filter outlet.
TECHNICAL PARAMETERS:
1.Norminal diameter: DN15-DN800
2.Working temperature: -30℃~200℃
3.Precisoin: 10-300 mesh
4.Sealing material: NBR, VITON
5.Working pressure: 1.0Mpa, 1.6Mpa
6.Body material: carbon steel, brass, stainless steel 201/304/316
